QLS-4100 Xe 4-57
Factory Reset
The factory reset feature of the QLS-4100 Xe returns all parameters available
through the printer’s front panel to their factory default values. Use the
procedure in this section to perform a factory reset to return the printer to
the default values listed below.
Factory default values
TCP/IP address 192.168.255.1
TCP/IP mask 255.255.255.1
TCP/IP gateway 0.0.0.0
Data port Parallel*
Parallel mode Auto
Baud rate 19200
RS232 handshaking DTR/DSR
Calibrate Continuous
Speed 3 in/sec
Intensity (heads 1-4) 16
Vertical offset 0
Horizontal offset 0
Counter Off
Mirror mode Off
Cut flag Off
Cut offset 0
Print line adj. (heads 1-3) 0
Cross web adj. (heads 1-4) 0
Vertical baseline 0
Horizontal baseline 0
Drop/Lift Adjust 6
Cutter Disabled
Ribbon sensor Enabled
Ribbon type Standard
Pull back Disabled
Applicator Disabled
Memory card write protect Off
Form stop adjust 0
Peel delay .5 sec
Print & Peel mode Off
*On printer models with a parallel port
