QLS-4100 Xe 4-31
Operation Menu
Operation options are accessed via the Operation menu. The following
sections detail each of the features within this menu category.
Pull Back
When the QLS-4100 Xe stops printing, a section of blank media will extend
from the printhead near the rear of the printer (print station #4) to the front
of the printer. When you start printing again, this section of blank media will
be advanced out of the QLS-4100 Xe as printing begins.
The pull back function allows you to pull back the blank media section.
When the next print job begins, the section will be used for printing. This
feature requires a compressed air connection and special hardware. It should
only be used in applications that have been pre-qualified by QuickLabel.
Contact QuickLabel for more information on the pull back function.
The pull back function provides two modes:
Pull Back (Manual) - In Manual mode, there are two ways to activate a
media pull back. One method involves selecting it from the Operation
menu. Alternately, the FORM FEED button can be used to quickly
activate the media pull back function.
Pull Back (Auto) - In Automatic mode, the printer automatically
performs the pull back operation after a queue is finished printing.
Note: The pull back feature must be enabled before use. The Pull Back
Enable/Disable function is available from the Options menu.
