QLS-4100 Xe 4-25
Vertical Baseline
This function is used to synchronize printing when using multiple
QLS-4100 Xe printers. If you are sending the same image file to two or more
printers and notice that the image prints in different vertical locations, you
can use this function to move the vertical baseline of a printer.
To adjust the vertical baseline:
1 If the printer is in a Ready state, press the PRINT/PAUSE key to pause
the printer.
2 Press the NEXT or PREVIOUS key until the Cal & Setup menu is
displayed. Then press the SELECT key.
3 Press the NEXT or PREVIOUS key until the Vertical Baseline menu is
displayed.
4 Press the + or – key until the desired baseline setting is displayed.
Baseline settings range from -120 through +120 dots.
5 Press the SELECT key to confirm the baseline.
6 Repeat this process on each printer requiring a baseline adjustment.
Vertical Baseline
Baseline = +0
Pause: Cal & Setup
Press SELECT
