4-42 Keypad controls and menus
4 Press the + or – key until the desired data port is displayed. Available
options are Parallel, Serial, or Ethernet.
5 Press the SELECT key to confirm your choice.
Parallel Mode
If you are using the parallel port to connect the printer to a host computer,
you can select a parallel port mode. The parallel port mode determines the
method of communication used between the host and the printer.
Note: This option is only available on printers with a parallel port.
The default setting is Auto mode. Auto mode attempts to communicate via
an ECP (Extended Capabilities Port) connection. If it cannot communicate via
this method, it will automatically switch to standard mode, which uses a
common Centronics method of communication.
The supplied parallel or high-speed IEEE-1284 parallel cable should be used
to ensure reliable performance.
To select a parallel mode:
1 If the printer is in a Ready state, press the PRINT/PAUSE key to pause
the printer.
2 Press the NEXT or PREVIOUS key until the Communications menu is
displayed. Then press the SELECT key.
3 Press the NEXT or PREVIOUS key until the Data Port menu is displayed.
4 Press the + or – key until the desired parallel mode is displayed.
Available options are Auto, or Standard.
5 Press the SELECT key to confirm your choice.
Parallel Mode
Auto
Pause: Communications
Press SELECT
