QLS-4100 Xe 8-3
Compatible Media
Standard QLS-4100 Xe media types including paper and synthetic may be
used. However, some flexible synthetic media types may not peel reliably
and it is recommended that any application be qualified by QuickLabel to
ensure reliable operation.
Print & Peel is to be used with adhesive backed labels on continuous liner.
Card stock or solid media cannot be used. Perforated liner cannot be used.
Round, Oval or clear labels will not trigger the peel sensor. In these cases a
remote input may be wired to trigger printing of the next label. For remote
input or other wiring information, contact QuickLabel Technical Support.
For some small diameter round labels (less than 4 inches) it may be possible
to adjust the form stop and still trigger the sensor with the label.
Compatible Media Specifications
Minimum Media Width 2 inches (51 mm)
Minimum Peel Length 1 inch (25 mm)
Maximum Peel Length 16.0 inches (400 mm)
Maximum Supply Roll
Diameter
Up to 12 inches (outside diameter)
Maximum Rewind Capacity Up to 10 inches (outside diameter)
This rewind capacity rewinds all liner from
the maximum supply roll.
