QLS-4100 Xe B-3
Dimensions 24” H x 15.5” D x 36” L
(610mm L x 394 mm D x 914mm L)
Weight 140 lbs. (64 kg) - no media, no ribbons
Power Requirements 20/240 VAC, 50/60 Hz, 6.3/4.0A
Compressed Air 1 cfm @ 70 psi required to operate RibbonRation™
Use Male NPT Plug with 3/8” body size.
(not supplied with printer)
Thermal Transfer Ribbon
4 rolls, each 3,281 ft long (1000m); Spot or CMYK
rolls
Label / Tag Size Width: 5.125” Max. (130mm), 2” Min. (51mm);
Length: 0.395” Min. (10mm)
Label / Tag Thickness 12 point Max. (0.16”, 0.007mm) recommended
Label / Tag Roll Capacity
12” Max. Outside Diameter (305mm)
