4-28 Keypad controls and menus
The sample report shown below indicates the type of information that
will be printed.
Notes: The OFFSET line displays the vertical offset, vertical baseline
(in parentheses), horizontal offset, horizontal baseline (in parentheses),
and the cut offset.
The “fmt err” value reports the last format error generated. This value
will be 0 if no format errors have occurred since power-up.
QLS-4100 Xe Settings:
SPEED = 2 INCHES/SEC
INTENSITY (1, 2, 3, 4): 15, 15, 15, 15
OFFSET: V = 0 (0), H = 0 (0), C = 0
PRINT LINE ADJ (1, 2, 3): -23, -9, -8
CROSS WEB ADJ (1, 2, 3, 4): 0, 0, < 7, <8
DROP/LIFT (1, 2, 3, 4): 12, 12, 12, 12
CONTINUOUS MEDIA 100 mm (1200 pixels)
CALIBRATION: YES (gap = 38 pixels)
COMPACT FLASH: NO
v01.4 (0x00:00:00:1D) (fmt err = 0)
MEDIA USE: (101) 198 meters
FILM 1 USE: (56) 56 meters
FILM 2 USE: (167) 167 meters
FILM 3 USE: (146) 146 meters
FILM 4 USE: (80) 80 meters
HEAD 1 USE: (31) 31 times
HEAD 2 USE: (54) 54 times
HEAD 3 USE: (42) 42 times
HEAD 4 USE: (20) 20 times
