7.7.3 I2NS Sonar Interface Module (SIM)
Figure 165: I2NS SIM Drawing
SECTION A-A
90.00 mm
[3.543 in]
280.00 mm
[11.024 in]
36.40mm
[1.433 in]
48.92mm
[1.926 in]
A
A
TOLERANCES
DO NOT SCALE DRAWING
DIMENSIONS ARE IN MILLIMETERS
UNLESS OTHERWISE SPECIFIED
X°
INTERNAL RADII
BREAK CORNERS
REMOVE ALL BURRS
.XX
.X
TITLE:
DATE:
RELEASED:
DATE:
DATE:
CHECKED:
DRAWING NO:
SIZE: SCALE:
DESIGNED:
DATE:
DWN:
SHEET:
OF
REV:
SANTA BARBARA, CALIFORNIA
INS SIM ENCLOSURE
10168 D
C
1/1
1 1
P Steenstrup
2013 06/10
P Steenstrup
2013 10/22
±1.0
±0.20
±0.5°
0.15/0.30
0.15/0.03
