2.6 Sonic 2022 Dimensions and Weights
Component
Dimensions (L x W x D) / Dry Weight
Receiver Module
276mm x 109mm x 190mm / 7.7kg
Projector
273mm x 108mm x 87mm / 3.3kg
Sonar Interface Module (SIM)
280mm x 170mm x 60mm / 2.4kg
I2NS Sonar Interface Module (SIM)
280mm x 170mm x 126.4mm / 4.2kg
Receive module and Projector mass in water
4.0kg (Fresh)
Table 7: 2022 Dimensions and Mass
2.7 Sonic 2026/2024/Sonic 2022 Electrical Interface
Item
Specification
Mains Power
90 – 260 VAC; 45 – 65 Hz
Power Consumption (SIM and Sonar Head)
125 Watt (2026); 75 Watt (2024); 54 Watt (2022)
Power Consumption (Sonar Head Only)
100W avg.; 150W peak (2026); 50W avg. 90W Peak
(2024); 35W avg.; 70W Peak (2022)
Integrated Inertial Navigation System (I2NS)
38.4W (SIM and IMU with Antennas)
Uplink/Downlink
10/100/1000Base-T Ethernet
Data Interface
10/100/1000Base-T Ethernet
Sync IN/OUT
TTL
GPS Timing
1PPS and RS232 NMEA or Ethernet time message
Auxiliary Sensors
RS232 / Ethernet
Deck Cable Length
15 metre (optional: 25m or 50 metres)
Table 8: Electrical Interface
2.8 Sonic MBES Ping Rates (SV = 1500.00m/sec)
RANGE
PING RATE
2 - 7
60.0
10
55.4
15
39.4
20
30.6
25
25.0
30
21.1
35
18.3
40
16.1
50
13.0
70
9.4
100
6.7
150
4.5
200
3.4
250
2.7
300
2.3
400
1.7
450
1.5
500
1.4
700
1.0
1000
0.7
1200
0.6
Table 9: Ping Rate table
WARNING
THE RECEIVE MODULE IS FILLED WITH
OIL THAT WILL FREEZE TO A SOLID AT
-10°C. STORAGE BELOW THIS
TEMPERATURE (TO -30°C) IS POSSIBLE
IF THE HEAD IS SLOWLY THAWED OUT
PRIOR TO OPERATION.
