R2Sonic 2026 - Figure 6: Sonic 2026 Acoustic Centre; Figure 7: Sonic 2026 Acoustic Centre, as Mounted

Page 31 of 254
Version
6.3
Rev
r012
Date
05-11-2022
Figure 6: Sonic 2026 Acoustic Centre
Figure 7: Sonic 2026 Acoustic Centre, as mounted
Centre of Flange to Alongship offset = 0.288m (0.944ft)
Top of Flange to Z reference = 0.318m (1.043ft)
Alongship ref
Athwartship
ref
Z
Reference
FORE
AFT
SONIC 2026 Side View
SONIC 2026 Plan View
187mm
240mm
Connector under
240
mm
Acoustic Centre
