5.11 Tools
5.11.1 Engineering
This area is for engineering commands to be sent to either the head or SIM for either
troubleshooting or system analysis. This area should not be used except by the direction of R2Sonic
engineers.
5.11.2 Firmware Update
FIREWALLS MUST BE
DISABLED. ALL VIRUS
CHECKERS MUST BE
When R2Sonic issues a firmware update, it will be made available to the customer, allowing the
customer to update their system by themselves. There are two firmware updates possible: SIM
update and/or sonar head update. The update file will be designated either Simb$ (SIM) or Head$
(sonar head); the extension will be *.bin. There is also an option to update the transmitter
firmware; this is not the same as the sonar head firmware.
Before updating the firmware, make sure that none of the computer’s other Ethernet ports are in
use; it may be necessary to shut down other sensors that use the Ethernet for data transfer.
Connect the SIM directly to the computer’s network interface card.
Place the update file in the Sonic Control directory, on the computer hard drive. Go to Tools |
Firmware Update; the files will be shown, if not use the browse button to search for the correct
upgrade file to download to either the SIM or the sonar head. If there is an upgrade for both the
sonar head and the SIM, it is recommended to upgrade the SIM first. Updates are not fully installed
until the system has been power cycled.
In Dual Head systems, the firmware update can only be applied to Sonar 1. To update Sonar 2, it
must be temporarily connected as Sonar 1.
