2.3 Sonic 2022 System Specification
System Feature
Specification
Frequency (Type 1006 Projector)
170kHz to 450kHz (700kHz optional)
Frequency (Type 1004 Projector)
200kHz to 400kHz
Beamwidth – Across Track (at nadir)
1.0°@ 400kHz / 2.0° @ 200kHz
Beamwidth – Along Track (at nadir)
0.9° @ 450kHz / 2.0° @ 200kHz
UHR Beamwidth (at nadir)
0.6° Across Track x 0.6° Along Track
Number of Beams
256
Swath Sector
10° to 160° (user selectable)
UHR Swath Sector
10° to 70° (user selectable)
Maximum Slant Range
1200 metres
Pulse Length
15µSec – 1115µSec
Pulse Type
Shaped Continuous Wave (CW)
Depth Rating
100 metres (4000 metres optional)
Operating Temperature
-10° C to 50° C
Storage Temperature
-30° C to 55° C
Table 4: 2020 System Specifications
2.4 Sonic 2026 Dimensions and Weights
Component
Dimensions (L x W x D) / Dry Weight
Receiver Module
480mm x 109mm x 190mm / 12.9kg
Projector
480mm x 109mm x 196mm /13.4kg
Sonar Interface Module (SIM)
280mm x 170mm x 60mm / 2.4kg
I2NS Sonar Interface Module (SIM)
280mm x 170mm x 126.4mm / 4.2kg
Projector mass in air / Rcvr and Proj. in Air
13.4kg (29.4lbs) / 26.3kg (57.2lbs)
Receive module and Projector mass in water
10.6kg (22.4lbs) Fresh
Table 5: 2026 Dimensions and Mass
2.5 Sonic 2024 Dimensions and Weights
Component
Dimensions (L x W x D) / Dry Weight
Receiver Module
480mm x 109mm x 190mm / 12.9kg
Projector
273mm x 108mm x 87mm / 3.3kg
Sonar Interface Module (SIM)
280mm x 170mm x 60mm / 2.4kg
I2NS Sonar Interface Module (SIM)
280mm x 170mm x 126.4mm / 4.2kg
Receive module and Projector mass in water
5.9kg (Fresh)
Table 6: 2024 Dimensions and Mass
