Figure 20: Upper bracket for Projector cable clamp
The lower bracket fits within the upper bracket and is placed under the cable, but not bolted to the
projector housing.
Figure 22: Projector cable clamp upper bracket
Figure 23: Projector cable clamp in place
Mounting bracket securing
bolts pass through the two
holes on the edge of the
upper block.
Figure 21: Projector cable clamp lower
bracket
