• Settings for Sonar 1:
Head IP: Any unique IP number within the network subnet.
Head BasePort: Any number between 49152 and 65535. Preferred is 65500.
SIM IP: Any unique IP number within the network subnet.
SIM BasePort: Any number between 49152 and 65535. Preferred is 65500.
GUI IP: Same IP number of the computer running the Sonic Control software.
GUI BasePort: Any number between 49152 and 65535. Preferred is 65500.
Bathy IP: IP number of the computer running bathymetry data collection software.
Bathy BasePort: a Base port number that the bathymetry data collection software
requires.
TruePix™/Snippets IP: IP number of the computer running snippets data collection
software.
TruePix™/Snippets BasePort: Base port number for Snippets, Snippets will be output on
a port, which is the base port plus 6. With a base port of 4000, Snippets will be on port
4006; TruePix™ will be on port 4001
Water Column IP: IP address of the computer to receive water column data
Water Column BasePort: Base port number for Water Column data; Water Column data
will be output on the base port plus 5. The default base port is 4000; Water Column data
will be on UDP 4005.
• Settings for Sonar 2:
All entries must be zero. Serial numbers are left blank.
• Once networking is set up, Sonic Control will automatically connect upon power-up; there
is no need to go back into the Network Settings
