R&S FPC Series User Manual

Remote Control
R&S
®
FPC
236User Manual 1178.4130.02 ─ 07
Note:
●
To turn on the harmonic disortion measurement, use CALCulate<n>:
MARKer<m>:FUNCtion:HARMonics[:STATe].
●
To turn on the AM modulation depth measurement, use CALCulate<n>:
MARKer<m>:FUNCtion:MDEPth[:STATe].
Suffix:
<n>, <m>
.
irrelevant
Parameters:
<Measurement> CPOWer
Selects the channel power measurement.
OBANdwidth | OBWidth
Selects the occupied bandwidth measurement (OBW).
TDMA
Selects the TDMA power measurement.
Example: //Select the channel power measurement
CALC:MARK:FUNC:POW:SEL CPOW
Manual operation: See "Channel Power" on page 361
See "TDMA Power" on page 361
See "Occupied Bandwidth" on page 361
CALCulate<n>:MARKer<m>:FUNCtion:POWer[:STATe] <State>
This command turns a power measurement on and off.
Suffix:
<n>, <m>
.
irrelevant
Parameters:
<State> ON | 1
Turns on the power measurement.
OFF | 0
Performs a basic spectrum measurement.
*RST: OFF | 0
Example: //Turn on OBW measurement
CALC:MARK:FUNC:POW:SEL OBW
CALC:MARK:FUNC:POW ON
//Return to basic spectrum measurement
CALC:MARK:FUNC:POW OFF
Manual operation: See "Spectrum" on page 360
See "Channel Power" on page 361
See "TDMA Power" on page 361
See "Occupied Bandwidth" on page 361
Remote Commands of the Spectrum Application
