R&S FPC Series User Manual

Remote Control
R&S
®
FPC
244User Manual 1178.4130.02 ─ 07
CALCulate<n>:MARKer<m>:FUNCtion:HARMonics[:STATe] <State>
This command turns the harmonic distortion measurement on and off.
Suffix:
<n>, <m>
.
irrelevant
Parameters:
<State> ON | 1
Turns on the harmonic distortion measurement.
OFF | 0
Performs a basic spectrum measurement.
*RST: OFF
Example: See CALCulate<n>:MARKer<m>:FUNCtion:HARMonics:
PRESet
Manual operation: See "Harmonic Distortion" on page 361
19.12.1.7 AM Modulation Depth
The following remote commands are exclusive to the AM Modulation depth measure-
ment.
Commands to configure AM modulation depth measurements described elsewhere.
●
Marker position on the x-axis (absolute):
CALCulate<n>:MARKer<m>:X
CALCulate<n>:DELTamarker<m>:X
Notes:
– For the AM modulation depth measurement, 3 markers are automatically posi-
tioned on the trace: One marker on the assumed carrier, the other two on the
sidebands.
– The position of (delta) marker 2 must be a value larger than the value of marker
1 (to the right of marker 1).
– When you move (delta) marker 2, (delta) marker 3 is automatically positioned
on the opposite sideband to the left of marker 1. The distance relative to
marker 1 for both (delta) markers 2 and 3 is the same.
●
Marker position on the x-axis (relative):
CALCulate<n>:DELTamarker<m>:X:RELative
CALCulate<n>:MARKer<m>:FUNCtion:MDEPth:RESult?...................................................244
CALCulate<n>:MARKer<m>:FUNCtion:MDEPth[:STATe]................................................... 245
CALCulate<n>:MARKer<m>:FUNCtion:MDEPth:RESult?
This command queries the results of the AM modulation depth measurement.
To get a valid result, you have to perform a complete sweep with synchronization to the
sweep end between activating the delta marker and reading out the result. This is only
possible in single sweep mode.
Remote Commands of the Spectrum Application
