R&S FPC Series User Manual

Remote Control
R&S
®
FPC
253User Manual 1178.4130.02 ─ 07
Prerequisites for this command
●
Select logarithmic scale for the y-axis (DISPlay<n>[:WINDow]:TRACe<t>:Y:
SPACing).
For a linear scale, you cannot modify the display range as it is fixed.
Suffix:
<n>
.
irrelevant
<t> irrelevant
Parameters:
<DisplayRange> <numeric value>
Range: 1 to 150 dB
*RST: 100 dB
Default unit: dB
Example: //Define display range
DISP:TRAC:Y:SPAC LOG
DISP:TRAC:Y 110dB
Manual operation: See "Range / Ref Position" on page 370
See "Range / Ref Position" on page 380
DISPlay<n>[:WINDow]:TRACe<t>:Y[:SCALe]:ADJust
This command automatically scales the y-axis.
Suffix:
<n>
.
irrelevant
<t> irrelevant
Example: //Adjust the y-axis
DISP:TRAC:Y:ADJ
Usage: Event
Manual operation: See "Range / Ref Position" on page 370
See "Auto Range" on page 370
See "Range / Ref Position" on page 380
See "Auto Range" on page 380
See "Auto Range" on page 400
DISPlay<n>[:WINDow]:TRACe<t>:Y[:SCALe]:RLEVel <ReferenceLevel>
This command defines the reference level.
Suffix:
<n>
.
irrelevant
<t> irrelevant
Remote Commands of the Spectrum Application
