R&S FPC Series User Manual

Remote Control
R&S
®
FPC
309User Manual 1178.4130.02 ─ 07
19.14.3 Amplitude
Commands to configure amplitude described elsewhere.
●
Reference level:
DISPlay<n>[:WINDow]:TRACe<t>:Y[:SCALe]:RLEVel
●
Preamplifier:
INPut:GAIN:STATe
●
Attenuation:
INPut:ATTenuation
INPut:ATTenuation:AUTO
INPut:ATTenuation:MODE
●
Impedance:
INPut:IMPedance
INPut:IMPedance:PAD
DISPlay<n>[:WINDow]:TRACe<t>:Y[:SCALe]:PDIVision.................................................... 309
DISPlay<n>[:WINDow]:TRACe<t>:Y[:SCALe]:PDIVision <Scale>
This command defines the range of the y-axis for the graphical results.
Suffix:
<n>
.
irrelevant
<t> irrelevant
Parameters:
<Scale> <numeric value> (integer only)
The unit depends on the result.
• PCT for AM results (0.1 to 100 % per grid division).
• Hz for FM results (1 kHz to 1 MHz per grid division).
Example: //Define grid scale of AM results (50 percent per grid)
CALC:FEED 'XTIM:AM'
DISP:TRAC:Y:PDIV 50
Manual operation: See "Deviation per Division" on page 389
19.14.4 Bandwidth
[SENSe:]ADEMod:BWIDth:DEModulation.........................................................................310
[SENSe:]ADEMod:BANDwidth:DEModulation................................................................... 310
[SENSe:]ADEMod:BWIDth:RDEViation............................................................................ 310
[SENSe:]ADEMod:BANDwidth:RDEViation.......................................................................310
[SENSe:]FILTer:DEMPhasis[:STATe]................................................................................ 310
[SENSe:]FILTer:DEMPhasis:TCONstant........................................................................... 311
[SENSe:]FILTer:LPASs....................................................................................................311
Remote Commands of the Analog Demodulation
