Table 5-1: Automatic Settings when switching between Local and Remote
Local to Remote Remote to Local
SENS:AVER:TCON REP SENS:AVER:TCON MOV
-
ABORT:ALL
INIT:ALL:CONT ON
DISP:MESS OFF DISP:MESS OFF
In each CALCulate block, where % is
set as an output unit
(UNIT:POWer:RATio DPCT),
UNIT:POWER:RATio O is set.
-
The automatic storage of the instru-
ment settings is deactivated in the non-
volatile memory.
The automatic storage of the instrument settings is reactivated in
the nonvolatile memory.
-
SYST:SPEED NORMal
SENS:BUFF:STAT OFF
SENS:AVER:STAT ON
SENS:TRACe:AVER:STAT ON
SENS:AVER:COUNt:AUTO OFF
- ContAv:
TRIG:DEL 0
TRIG:HOLD 0
TRIG:SOUR IMM
TRIG:DEL:AUTO OFF
TRIG:COUNt 1
TRIG:ATR OFF
Burst, timegate, timeslot and
trace:
TRIG:DEL:AUTO OFF
TRIG:COUNt 1
TRIG:ATR OFF
5.6 Communication on Data Lines
The GPIB bus is the most common remote interface for measuring instruments. It has
also been implemented in the R&S NRP2. The remote controller and the R&S NRP2
communicate by means of messages. The messages sent on the data lines (chapter A,
"Remote control interfaces", on page 349) can be divided into two groups:
●
Interface messages
●
Device-dependent messages
5.6.1 Interface Messages
Interface messages are transmitted on the data lines of the IEC/IEEE bus when the ATN
control line is active. Interface messages allow the controller and the instrument to com-
municate and can only be sent by a controller which serves as the IEC/IEEE-bus con-
troller. Interface commands can be further classified as:
●
common commands
Communication on Data Lines
