3.6 Display windows
3.6.1 Window sizes and types
Results are displayed in the main section of the screen in windows. Windows come in
three sizes: half height, quarter height and full height. In windows, measurement results
are displayed digitally, in a combined digital and analog mode, and graphically.
See chapter 4.3, "Displaying measurement results", on page 90 for instructions on
selecting these modes.
"Dig" window, full height "Dig" window, half height
"Graph" trace window, full height "Graph" trace window, half height
Display windows
