The following commands affect this table:
●
MEMory:CLEar[:NAMe] <string>
●
MEMory:CLEar:TABLe
●
all MEMory:TABLe commands
The selection is not changed in case of an *RST or a SYSTem:PRESet
RST value: none
Error messages:
-256 "File name not found": A table named <select> is not known .
6.10 OUTPut
The OUTPut system serves for generator configuration. The R&S NRP2 can be equipped
with an optional RF test generator which produces a reference power of 1 mW at 50 MHz.
Moreover, the analog outputs at the rear of the power meter can be configured.
OUTPut:RECorder<[1]..2>:FEED.....................................................................................253
OUTPut:RECorder<[1]..2>:LIMit:LOWer...........................................................................254
OUTPut:RECorder<[1]..2>:LIMit:LOWer:POWer................................................................254
OUTPut:RECorder<[1]..2>:LIMit:LOWer:RATio.................................................................254
OUTPut:RECorder<[1]..2>:LIMit:UPPer............................................................................255
OUTPut:RECorder<[1]..2>:LIMit:UPPer:POWer................................................................255
OUTPut:RECorder<[1]..2>:LIMit:UPPer:RATio..................................................................255
OUTPut:RECorder<[1]..2>[:STATe].................................................................................256
OUTPut:ROSCillator[:STATe]..........................................................................................256
OUTPut:ROSCillator:CALibration:READ?.........................................................................256
OUTPut:ROSCillator:CALibration:WRIte...........................................................................256
OUTPut:TTL:ACTive......................................................................................................257
OUTPut:TTL:FAIL..........................................................................................................257
OUTPut:TTL:FEED........................................................................................................258
OUTPut:TTL:HVOLtage..................................................................................................258
OUTPut:TTL:LVOLtage..................................................................................................258
OUTPut:TTL[:STATe].....................................................................................................258
OUTPut:TRIGger[:STATe]..............................................................................................259
OUTPut:RECorder<[1]..2>:FEED <calculate_block>
Assigns a calculate block to one of the two analog outputs. On the basis of the set char-
acteristic, the measured value is converted to a DC voltage that can be tapped at the
appropriate output.
Parameters:
<calculate_block> "CALC1", "CALC2", "CALC3", "CALC4"
*RST: output 1: "CALC1"; output 2: "CALC2"
OUTPut
