R&S NRP2 - Correspondence between Remote Control and Manual Control

Remote Control Fundamentals
R&S
®
NRP2
184User Manual 1173.9157.02 ─ 03
SCPI command Value Remark
TRIGger[1..4]:SOURce EXTernal |
INTernal
User-selectable.
TRIGger[1..4]:SLOPe POSitive |
NEGative
User-selectable.
TRIGger[1..4]:COUNt
1 Cannot be modified in manual mode.
TRIGger[1..4]:DELay 0 S
Cannot be modified in manual mode.
TRIGger[1..4]:HOLDoff
Depends on sensor User-selectable.
TRIGger[1..4]:LEVel
Depends on sensor User-selectable.
[SENSe[1..4]]:TIMing:EXCLude:
STARt
0 S
Cannot be modified in manual mode.
[SENSe[1..4]]:TIMing:EXCLude:STOP 0 S
Cannot be modified in manual mode.
INITiate[1..4]:CONTinuous ON
Cannot be modified in manual mode.
5.10 Correspondence between Remote Control and Manual
Control
The following table compares the control elements of the graphical user interface for
manual control with the SCPI commands for remote control in order to simplify the transfer
of manual control procedures to a remote control program.
Menu item in manual control SCPI command in short form
Sensor→Mode
SENS[1..4]:FUNCtion
Sensor→Mode→ContAv→Aperture
SENS[1..4]:APER
Sensor→Mode→ContAv→Sampling Rate
SENS[1..4]:SAMP
Sensor→Mode→ContAv→DutyCycle
SENS[1..4]:CORR:DCYC
Sensor→Mode→ContAv→DutyCycle
SENS[1..4]:CORR:DCYC:STAT
Sensor→Mode→ContAv→Smoothing of Modu-
lated Signals
SENS[1..4]:SMO:STAT
Sensor→Mode→Burst→Dropout
SENS[1..4]:BURSt:DTOL
Sensor→Mode→Burst→Exclude Start
SENS[1..4]:TIM:EXCL:STAR
Sensor→Mode→Burst→Exclude Stop
SENS[1..4]:TIM:EXCL:STOP
Sensor→Mode→Timeslot→No. of Timeslots
SENS[1..4]:POW:TSL:COUN
Sensor→Mode→Timeslot→Nominal Width
SENS[1..4]:POW:TSL:WIDT
Sensor→Mode→Timeslot→Exclude Start
SENS[1..4]:TIM:EXCL:STAR
Sensor→Mode→Timeslot→Exclude Stop
SENS[1..4]:TIM:EXCL:STOP
Sensor→Mode→Timeslot→Fence→Start
SENS[1..4]:TSL:EXCL:MID:OFFS
