R&S NRP2 - Standard Configurations

Standard Configurations
R&S
®
NRP2
366User Manual 1173.9157.02 ─ 03
Sensor parameter Remote control command in
short form
Value
Timegate Offset
SENS:TGAT:OFFS:TIME
1: 20 µs
2: 2.328 ms
Timegate Length
SENS:TGAT:TIME
1: 527 µs
2: 527 µs
Timegate Fence
SENS:TGAT:MID OFF
Trace Offset Time
SENS:TRAC:OFFS:TIME
-50 µs
Trace Capture Time
SENS:TRAC:TIME
5 ms
Trace Number Of Points
SENS:TRAC:POIN
261
Trace Realtime
SENS:TRAC:REAL OFF
Trigger Delay
TRIG:DEL
0 s
Trigger Level
TRIG:LEV
-20 dBm
Trigger Source
TRIG:SOUR INT
Trigger Slope
TRIG:SLOP POS
Trigger Holdoff
TRIG:HOLD
27 ms
Trigger Dropout Time
TRIG:DTIM
0 s
Trigger Hysteresis
TRIG:HYST
3 dB
Table 2-2: NADC/DOWNLINK
Sensor parameter Remote control command in
short form
Value
Sensor Mode SENS:FUNC
POW:AVG
Aperture Time SENS:APER 40 ms
Duty Cycle Correction SENS:DCYC:STAT
OFF
Smoothing SENS:SMO
OFF
Trigger Source TRIG:SOUR
EXT
Table 2-3: NADC/UPLINK
Sensor parameter Remote control command in
short form
Value
Sensor Mode
SENS:FUNC POW:XTIM
Aperture Time
SENS:APER
40 ms
Duty Cycle
SENS:DCYC
16.267 %
Duty Cycle Correction
SENS:DCYC:STAT ON
Smoothing
SENS:SMO OFF
Dropout Tolerance
SENS:BURST:DTOL
3 ms
