Standard Configurations
R&S
®
NRP2
367User Manual 1173.9157.02 ─ 03
Sensor parameter Remote control command in
short form
Value
Exclude Time Start
SENS:TIM:EXCL:STAR
130 µs
Exclude Time End
SENS:TIM:EXCL:STOP
140 µs
Number Of Timeslots
SENS:TSL:COUN
6
Timeslot Width
SENS:TSL:WIDT
6.667 ms
Timeslot Fence
SENS:TSL:MID OFF
Timegate Offset
SENS:TGAT:OFFS:TIME
1: 130 µs
2: 20.130 ms
Timegate Length
SENS:TGAT:TIME
1: 6.390 ms
2: 6.390 ms
Timegate Fence
SENS:TGAT:MID OFF
Trace Offset Time
SENS:TRAC:OFFS:TIME
-500 µs
Trace Capture Time
SENS:TRAC:TIME
42 ms
Trace Number Of Points
SENS:TRAC:POIN
261
Trace Realtime
SENS:TRAC:REAL OFF
Trigger Delay
TRIG:DEL
0 s
Trigger Level
TRIG:LEV
-30 dBm
Trigger Source
TRIG:SOUR INT
Trigger Slope
TRIG:SLOP POS
Trigger Holdoff
TRIG:HOLD
79 ms
Trigger Dropout Time
TRIG:DTIM
0 s
Trigger Hysteresis
TRIG:HYST
3 dB
Table 2-4: PDC/DOWNLINK
Sensor parameter Remote control command in
short form
Value
Sensor Mode
SENS:FUNC POW:AVG
Aperture Time
SENS:APER
40 ms
Duty Cycle Correction
SENS:DCYC:STAT OFF
Smoothing
SENS:SMO OFF
Trigger Source
TRIG:SOUR EXT
