Remote Control Fundamentals
R&S
®
NRP2
190User Manual 1173.9157.02 ─ 03
Menu item in manual control SCPI command in short form
Sensor→Mode→Trace&Statistics
Windows→Graph
Display→Pulse→
Pulse Width
Pulse Period
Duty Cycle
Pulse Off Time
Rise Time
Fall Time
Start Time
Stop Time
Pulse Top
Pulse Base
Trace Avg
Trace Peak
Trace Min
Pos. Overshoot
Neg. Overshoot
SENS:TRAC:MEAS:PULS:DUR?
SENS:TRAC:MEAS:PULS:PER?
SENS:TRAC:MEAS:PULS:DCYC?
SENS:TRAC:MEAS:TRAN:POS:DUR?
SENS:TRAC:MEAS:TRAN:NEG:DUR?
SENS:TRAC:MEAS:TRAN:POS:OCC?
SENS:TRAC:MEAS:TRAN:NEG:OCC?
SENS:TRAC:MEAS:POW:PULS:TOP?
SENS:TRAC:MEAS:POW:PULS:BAS?
SENS:TRAC:MEAS:POW:AVG?
SENS:TRAC:MEAS:POW:MAX?
SENS:TRAC:MEAS:POW:MIN?
SENS:TRAC:MEAS:TRAN:POS:OVER?
SENS:TRAC:MEAS:TRAN:NEG:OVER?
Sensor→Mode→Trace&Statistics
Windows→Graph
Config Pulse...→
Configure Algorithm
Ref.Power
High Ref Power
Low Ref Power
SENS:TRAC:MEAS:ALG
SENS:TRAC:MEAS:DEF:DUR:ERF
SENS:TRAC:MEAS:DEF:TRAN:HREF
SENS:TRAC:MEAS:DEF:TRAN:LREF
Sensor→Mode→Trace&Statistics
Windows→Graph
Config Pulse...→Config Related to
Measurements are always related to power
Correspondence between Remote Control and Manual Control
