Renesas M16C/29 Series User Manual

13. Timer S
puorG92/C61M
page 149
854fo7002,03.raM21.1.veR
2110-1010B90JER
Figure 13.9 G1IR Register
Interrupt Request Register
(1)
Symbol Address After Reset
G1IR 0330 16 Undefined
b7 b6 b5 b4 b3 b2 b1 b0
RW
RW
RW
RW
RW
RW
RW
RW
RW
Bit Name
Bit
Symbol
G1IR0
G1IR1
G1IR2
Interrupt request, Ch0
G1IR3
G1IR4
G1IR5
G1IR7
Function
G1IR6
0 : No interrupt request
1 : Interrupt requested
Interrupt request, Ch1
Interrupt request, Ch2
Interrupt request, Ch3
Interrupt request, Ch4
Interrupt request, Ch5
Interrupt request, Ch6
Interrupt request, Ch7
NOTE:
1. When writing 0 to each bit in the G1IR register, use the following instruction:
AND, BCLR
