13. Timer S
puorG92/C61M
page 161
854fo7002,03.raM21.1.veR
2110-1010B90JER
13.5 Waveform Generating Function
Waveforms are generated when the base timer value matches the G1POj (j=0 to 7) register value.
The waveform generating function has the following three modes :
• Single-phase waveform output mode
• Phase-delayed waveform output mode
• Set/Reset waveform output (SR waveform output) mode
Table 13.7 lists registers associated with the waveform generating function.
Table 13.7 Registers Related to the Waveform Generating Function Settings
Register Bit Function
G1POCRj MOD1 to MOD0 Select output waveform mode
IVL Select default value
RLD Select G1POj register value reload timing
INV Select inverse output
G1POj - Select timing to output waveform inverted
G1FS FSCj Set to 0 (waveform generating function)
G1FE IFEj Set to 1 (enables function on channel j)
j = 0 to 7
Bit configurations and functions vary with channels used.
Registers associated with the waveform generating function must be set after setting registers associated with the base timer.
