Renesas M16C/29 Series User Manual

12. Timer (Three-phase Motor Control Timer Function)
puorG92/C61M
page 125
854fo7002,03.raM21.1.veR
2110-1010B90JER
12.3 Three-phase Motor Control Timer Function
Timers A1, A2, A4 and B2 can be used to output three-phase motor drive waveforms. Table 12.10 lists the
specifications of the three-phase motor control timer function. Figure 12.24 shows the block diagram for
three-phase motor control timer function. Also, the related registers are shown on Figures 12.26 to 12.32.
Table 12.10 Three-phase Motor Control Timer Function Specifications
Item Specification
Three-phase waveform output pin
___ ___ ___
Six pins (U, U, V, V, W, W)
Forced cutoff input
(1)
_____
Input “L” to SD pin
Used Timers Timer A4, A1, A2 (used in the one-shot timer mode)
___
Timer A4: U- and U-phase waveform control
___
Timer A1: V- and V-phase waveform control
___
Timer A2: W- and W-phase waveform control
Timer B2 (used in the timer mode)
Carrier wave cycle control
Dead time timer (3 eight-bit timer and shared reload register)
Dead time control
Output waveform Triangular wave modulation, Sawtooth wave modification
Enable to output “H” or “L” for one cycle
Enable to set positive-phase level and negative-phase
level respectively
Carrier wave cycle Triangular wave modulation: count source x (m+1) x 2
Sawtooth wave modulation: count source x (m+1)
m: Setting value of TB2 register, 0 to 65535
Count source: f1, f2, f8, f32, fC32
Three-phase PWM output width Triangular wave modulation: count source x n x 2
Sawtooth wave modulation: count source x n
n: Setting value of TA4, TA1 and TA2 register (of TA4,
TA41, TA1, TA11, TA2 and TA21 registers when setting
the INV11 bit to 1), 1 to 65535
Count source: f1, f2, f8, f32, fC32
Dead time Count source x p, or no dead time
p: Setting value of DTT register, 1 to 255
Count source: f1, f2, f1 divided by 2, f2 divided by 2
Active level Eable to select “H” or “L”
Positive and negative-phase concurrent Positive and negative-phases concurrent active disable
function
Positive and negative-phases concurrent active detect func-
tion
Interrupt frequency For Timer B2 interrupt, select a carrier wave cycle-to-cycle
basis through 15 times carrier wave cycle-to-cycle basis
NOTE:
1. When the INV02 bit in the INVC0 register is set to 1 (three-phase motor control timer function), the
_____ _____
SD function of the P85/SD pin is enabled. At this time, the P85 pin cannot be used as a programmable
_____ _____
I/O port. When the SD function is not used, apply “H” to the P85/SD pin.
_____
When the IVPCR1 bit in the TB2SC register is set to 1 (enable three-phase output forced cutoff by SD
_____
pin input), and “L” is applied to the SD pin, the related pins enter high-impedance state regardless of
the functions which are used. When the IVPCR1 bit is set to 0 (disabled three-phase output forced
_____ _____
cutoff by SD pin input) and “L” is applied to the SD pin, the related pins can be selected as a program-
mable I/O port and the setting of the port and port direction registers are enable.
Related pins: P72/CLK2/TA1OUT/V/RXD1
_________ _________ ___
P73/CTS2/RTS2/TA1IN/V/TXD1
P74/TA2OUT/W
____
P75/TA2IN/W
P80/TA4OUT/U
___
P81/TA4IN/U
