13. Timer S
puorG92/C61M
page 169
854fo7002,03.raM21.1.veR
2110-1010B90JER
13.6.1 INPC17 Alternate Input Pin Selection
The input capture pin for IC/OC channel 7 can be assigned to one of two package pins. The CH7INSEL
________
bit in the G1BCR0 register selects IC/OC INPC17 from P27/OUTC17/INPC17 or P17/INT5/INPC17/IDU.
________
13.6.2 Digital Debounce Function for Pin P17/INT5/INPC17
________ ________
The INT5/INPC17 input from the P17/INT5/INPC17/IDU pin has an effective digital debounce function
against a noise rejection. Refer to 19.6 Digital Debounce function for this detail.
