14.1.5 Special Mode 3 (IEBus mode)(UART2)
In this mode, one bit in the IEBus is approximated with one byte of UART mode waveform.
Table 14.17 lists the registers used in IEBus mode and the register values set. Figure 14.30 shows the
functions of bus collision detect function related bits.
If the TxD2 pin output level and RxD2 pin input level do not match, a UART2 bus collision detect interrupt
request is generated.
Table 14.17 Registers to Be Used and Settings in IEBus Mode
Register Bit Function
U2TB 0 to 8 Set transmission data
U2RB
(1)
0 to 8 Reception data can be read
OER,FER,PER,SUM
Error flag
U2BRG 0 to 7 Set bit rate
U2MR SMD2 to SMD0 Set to 1102
CKDIR Select the internal clock or external clock
STPS Set to 0
PRY Invalid because PRYE is set to 0
PRYE Set to 0
IOPOL Select the TxD/RxD input/output polarity
U2C0 CLK1, CLK0 Select the count source for the U2BRG register
CRS Invalid because CRDis set to 1
TXEPT Transmit register empty flag
CRD Set to 1
NCH Select TxD2 pin output mode
CKPOL Set to 0
UFORM Set to 0
U2C1 TE Set this bit to 1 to enable transmission
TI Transmit buffer empty flag
RE Set this bit to 1 to enable reception
RI Reception complete flag
U2IRS Select the source of UART2 transmit interrupt
U2RRM, Set to 0
U2LCH, U2ERE
U2SMR 0 to 3, 7 Set to 0
ABSCS Select the sampling timing at which to detect a bus collision
ACSE Set this bit to 1 to use the auto clear function of transmit enable bit
SSS Select the transmit start condition
U2SMR2 0 to 7 Set to 0
U2SMR3 0 to 7 Set to 0
U2SMR4 0 to 7 Set to 0
NOTE:
1. Not all register bits are described above. Set those bits to 0 when writing to the registers in IEBus mode.
