13. Timer S
puorG92/C61M
page 150
854fo7002,03.raM21.1.veR
2110-1010B90JER
Figure 13.10 G1IE0 and G1IE1 Registers
Interrupt Enable Register 0
Symbol Address After Reset
G1IE0 0331 16 00 16
b7 b6 b5 b4 b3 b2 b1 b0
RW
RW
RW
RW
RW
RW
RW
RW
RW
Bit Name
Bit
Symbol
G1IE00
G1IE01
G1IE02
Interrupt enable 0, CH0
G1IE03
G1IE04
G1IE05
G1IE07
Function
G1IE06
0 : IC/OC interrupt 0 request disable
1 : IC/OC interrupt 0 request enable
Interrupt enable 0, CH1
Interrupt enable 0, CH2
Interrupt enable 0, CH3
Interrupt enable 0, CH4
Interrupt enable 0, CH5
Interrupt enable 0, CH6
Interrupt enable 0, CH7
Interrupt Enable Register 1
Symbol Address After Reset
G1IE1 0332 16 00 16
b7 b6 b5 b4 b3 b2 b1 b0
RW
RW
RW
RW
RW
RW
RW
RW
RW
Bit Name
Bit
Symbol
G1IE10
G1IE11
G1IE12
Interrupt enable 1, CH0
G1IE13
G1IE14
G1IE15
G1IE17
Function
G1IE16
0 : IC/OC interrupt 1 request disable
1 : IC/OC interrupt 1 request enable
Interrupt enable 1, CH1
Interrupt enable 1, CH2
Interrupt enable 1, CH3
Interrupt enable 1, CH4
Interrupt enable 1, CH5
Interrupt enable 1, CH6
Interrupt enable 1, CH7
