4. Special Function Registers (SFRs)
puorG92/C61M
page 24
854fo7002,03.raM21.1.veR
2110-1010B90JER
Address Register Symbol After reset
0000
16
0001
16
0002
16
0003
16
0004
16
Processor mode register 0 PM0 0016
0005
16
Processor mode register 1 PM1 000010002
0006
16
System clock control register 0 CM0 010010002
0007
16
System clock control register 1 CM1 001000002
0008
16
0009
16
Address match interrupt enable register AIER XXXXXX002
000A
16
Protect register PRCR XX0000002
000B
16
000C
16
Oscillation stop detection register (Note 2) CM2 0X0000102
000D
16
000E
16
Watchdog timer start register WDTS XX16
000F
16
Watchdog timer control register WDC 00XXXXXX2
0010
16
Address match interrupt register 0 RMAD0 0016
0011
16
0016
0012
16
X016
0013
16
0014
16
Address match interrupt register 1 RMAD1 0016
0015
16
0016
0016
16
X016
0017
16
0018
16
0019
16
Voltage detection register 1 (Note 3,4) VCR1 000010002
001A
16
Voltage detection register 2 (Note 3,4) VCR2 0016
001B
16
001C
16
PLL control register 0 PLC0 0001X0102
001D
16
001E
16
Processor mode register 2 PM2 XXX000002
001F
16
Low voltage detection interrupt register (Note 4) D4INT 0016
0020
16
DMA0 source pointer SAR0 XX16
0021
16
XX16
0022
16
XX16
0023
16
0024
16
DMA0 destination pointer DAR0 XX16
0025
16
XX16
0026
16
XX16
0027
16
0028
16
DMA0 transfer counter TCR0 XX16
0029
16
XX16
002A
16
002B
16
002C
16
DMA0 control register DM0CON 00000X002
002D
16
002E
16
002F
16
0030
16
DMA1 source pointer SAR1 XX16
0031
16
XX16
0032
16
XX16
0033
16
0034
16
DMA1 destination pointer DAR1 XX16
0035
16
XX16
0036
16
XX16
0037
16
0038
16
DMA1 transfer counter TCR1 XX16
0039
16
XX16
003A
16
003B
16
003C
16
DMA1 control register DM1CON 00000X002
003D
16
003E
16
003F
16
Note 1: The blank areas are reserved and cannot be used by users.
Note 2: Bits CM20, CM21, and CM27 do not change at oscillation stop detection reset.
Note 3: This register does not change at software reset, watchdog timer reset and oscillation stop detection reset.
Note 4: This registe can not use for T-ver. and V-ver.
X : Undefined
4. Special Function Registers (SFRs)
SFRs (Special Function Registers) are the control registers of peripheral functions. Table 4.1 to 4.11 list the
SFR address map.
Table 4.1 SFR Information (1)
