4. Special Function Registers (SFRs)
puorG92/C61M
page 33
854fo7002,03.raM21.1.veR
2110-1010B90JER
Address Register Symbol After reset
0380
16
Count start flag TABSR 00
16
0381
16
Clock prescaler reset flag CPSRF 0XXXXXXX
2
0382
16
One-shot start flag ONSF 00
16
0383
16
Trigger select register TRGSR 00
16
0384
16
Up-dowm flag UDF 00
16
0385
16
0386
16
Timer A0 register TA0 XX
16
0387
16
XX
16
0388
16
Timer A1 register TA1 XX
16
0389
16
XX
16
038A
16
Timer A2 register TA2 XX
16
038B
16
XX
16
038C
16
Timer A3 register TA3 XX
16
038D
16
XX
16
038E
16
Timer A4 register TA4 XX
16
038F
16
XX
16
0390
16
Timer B0 register TB0 XX
16
0391
16
XX
16
0392
16
Timer B1 register TB1 XX
16
0393
16
XX
16
0394
16
Timer B2 register TB2 XX
16
0395
16
XX
16
0396
16
Timer A0 mode register TA0MR 00
16
0397
16
Timer A1 mode register TA1MR 00
16
0398
16
Timer A2 mode register TA2MR 00
16
0399
16
Timer A3 mode register TA3MR 00
16
039A
16
Timer A4 mode register TA4MR 00
16
039B
16
Timer B0 mode register TB0MR 00XX0000
2
039C
16
Timer B1 mode register TB1MR 00XX0000
2
039D
16
Timer B2 mode register TB2MR 00XX0000
2
039E
16
Timer B2 special mode register TB2SC X0000000
2
039F
16
03A0
16
UART0 transmit/receive mode register U0MR 00
16
03A1
16
UART0 bit rate register U0BRG XX
16
03A2
16
UART0 transmit buffer register U0TB XX
16
03A3
16
XX
16
03A4
16
UART0 transmit/receive control register 0 U0C0 00001000
2
03A5
16
UART0 transmit/receive control register 1 U0C1 00000010
2
03A6
16
UART0 receive buffer register U0RB XX
16
03A7
16
XX
16
03A8
16
UART1 transmit/receive mode register U1MR 00
16
03A9
16
UART1 bit rate register U1BRG XX
16
03AA
16
UART1 transmit buffer register U1TB XX
16
03AB
16
XX
16
03AC
16
UART1 transmit/receive control register 0 U1C0 00001000
2
03AD
16
UART1 transmit/receive control register 1 U1C1 00000010
2
03AE
16
UART1 receive buffer register U1RB XX
16
03AF
16
XX
16
03B0
16
UART transmit/receive control register 2 UCON X0000000
2
03B1
16
03B2
16
03B3
16
03B4
16
CRC snoop address register CRCSAR XX
16
03B5
16
00XXXXXX
2
03B6
16
CRC mode register CRCMR 0XXXXXX0
2
03B7
16
03B8
16
DMA0 request cause select register DM0SL 00
16
03B9
16
03BA
16
DMA1 request cause select register DM1SL 00
16
03BB
16
03BC
16
CRC data register CRCD XX
16
03BD
16
XX
16
03BE
16
CRC input register CRCIN XX
16
03BF
16
Note 1: The blank areas are reserved and cannot be used by users.
X : Undefined
Table 4.10 SFR Information (10)
