Technical Bulletin PAGE: 7/11
Reissued:27-Mar-14
Model: CH-C1 Finisher SR4110
Date: 11-Oct-13
No.: RD135038a
Finisher D707 to Main Machine or Other Upstream Unit
1. Remove the connector cover [A].
2. Fasten the joint bracket [B] to the Copier.
3. Attach the coupling seal [A] to the copier.
4. Dock the finisher. (See “Connecting the Finisher D707”)
