Electrical Component Functions
SM 6-47 J007/J010/J011
J007/J010/
J011
No. Component Function
Thermistor
TH Thermistor
This is a small bulb thermistor on the end of a wire and
attached to the HRB. This thermistor measures the
temperature around the print heads.
