Ricoh M047 - Page 173

SP Tables
SM Appendix 3-11 M047
Appendix: SP
Mode Tables
1002
Side to Side Reg
Adjusts the printing side-to-side registration from the 1st paper feed station
using the trimming area pattern (SP2-902 No.12).
Push [
] or [ ] to select the settings (plus or minus).
Specification: 0 ±2.0 mm.
1002 1 BypassTray
[-40 to +40 / 0 / 1 mm]
1002 2 MainTray1
1002 3 MainTray2
1002 4 BankTray1
1002 5 BankTray2
1002 6 Duplex
1003
Regist sag
Adjusts the relay clutch timing at registration. Relay clutch timing
determines the amount of paper buckle at registration. (A "+" setting causes
more buckling.)
1003 1 BypassTray Plain
[–8 to 8 / 0 / 1 mm step]
1003 2 BypassTray Thick
1003 3 BypassTray Thick2
1003 4 MainTray Plain
1003 5 MainTray Thick
1003 6 MainTray Thick2
1003 7 BankTray Plain
1003 8 BankTray Thick
1003 9 BankTray Thick2
