Rockwell Automation Publication 2713P-UM001G-EN-P - May 2022 11
Chapter 1
Overview
About the PanelView 5310
Terminals
The PanelView™ 5310 terminals are operator interface devices that monitor and
control devices attached to ControlLogix® 5570 or 5580 controllers or
CompactLogix™ 5370, 5380, or 5480 controllers over an EtherNet/IP™ network.
Animated graphic and text displays provide operators with a view into the
operating state of a machine or process. Operators interact with the control
system by using the touch screen.
The PanelView 5310 terminals include these features and capabilities:
• Tightly integrated control and design environment allows information to
be shared between the PanelView 5310 terminal and the Logix platforms.
• The Studio 5000® environment provides one point of access for the Studio
5000 View Designer® and Studio 5000 Logix Designer® applications.
(1)
• Connection to one ControlLogix 5570 or 5580 controller or one
CompactLogix 5370, 5380, or 5480 controller with revision 27 firmware
or later.
• Supports a maximum of 100 user-defined screens.
• Supports a maximum of 4,000 Logix-based alarms.
(1)
• Easily configured screen navigation menu.
• Automatic Diagnostics capability.
• Conformal coating available for all terminal sizes.
Topic Page Topic Page
About the PanelView 5310 Terminals 11 EtherNet/IP Communication 15
Hardware Features 12 Typical Configuration 15
Operator Control 13 Catalog Number Explanation 16
Touch Gestures 13 Product Selections 16
Studio 5000 Environment 14 Accessories 16
(1) PanelView 5310 firmware can support up to 4,000 Logix-based alarms in one controller if you use Studio 5000 View Designer
application version 5 and Studio 5000 Logix Designer application version 32 or higher. Of the 4,000 alarms, no more than 1,000 can
be instruction-based. Earlier versions of the Studio 5000 View Designer or Studio 5000 Logix Designer applications can support up
to 1,000 Logix-based alarms.
