16 Rockwell Automation Publication 2713P-UM001G-EN-P - May 2022
Chapter 1
Catalog Number
Explanation
This table provides an explanation of the catalog numbers.
Product Selections
This table provides information for the product selections.
Accessories
Tab l e 3 through Tab l e 7 list accessories for the PanelView 5310 terminals.
Bulletin Input Type Display Size Display Type Power Ethernet Port – Special Option
|| | || ||
2713P- T = Touch 6 = 5.7-in. C = Color, 4:3 aspect ratio D = DC 1 = Single – B = Without brand identity
(2)
7 = 7-in. W = Color, widescreen
(1)
aspect ratio K = Conformal coating
(3)
9 = 9-in.
10 = 10.4-in.
12 = 12.1-in.
(1) Depending on the PanelView 5310 terminal model, the widescreen aspect ratio is either 5:3 or 16:10. For further details, see the Product Selections section on this page.
(2) A catalog number with -B at its end (for example, 2713P-T9WD1-B) is a terminal without the Allen-Bradley logo and product identification on the front bezel.
(3) A catalog number with -K at its end (for example, 2713P-T6CD1-K) is a terminal with conformal coating.
Cat. No. Display
Input
Power
Ethernet
Port
Memory
Touch Screen Display Size Type
Aspect
Ratio
Pixels
(W x H) RAM User
(1)
2713P-T6CD1
2713P-T6CD1-B
2713P-T6CD1-K
5.7-in. VGA
TFT color
4:3 640 x 480 DC One 1 GB 1 GB
2713P-T7WD1
2713P-T7WD1-B
2713P-T7WD1-K
7-in. WVGA
TFT color
5:3 800 x 480
2713P-T9WD1
2713P-T9WD1-B
2713P-T9WD1-K
9-in.
2713P-T10CD1
2713P-T10CD1-B
2713P-T10CD1-K
10.4-in. SVGA
TFT color
4:3 800 x 600
2713P-T12WD1
2713P-T12WD1-B
2713P-T12WD1-K
12.1-in. WXGA
TFT color
16:10 1280 x 800
(1) Nonvolatile memory that is available to store projects.
Table 3 - Power Supplies and Power Terminal Blocks
Cat. No. Description Quantity
1606-XLB120E DIN rail power supply, 24…28V DC output voltage, 120 W 1
1606-XLP100E DIN rail power supply, 24…28V DC output voltage, 100 W 1
1606-XLP95E DIN rail power supply, 24…28V DC output voltage, 95 W 1
2711-TBDC 3-pin DC power terminal block 10
