Rockwell Automation Publication 2713P-UM001G-EN-P - May 2022 55
Chapter 3
Modify Screen Color
Settings By Using HMI
Device Tags
If you need to adjust the color of the PanelView 5000 LCD display, there are
three HMI device tags available under the Display category:
•BlueAdjustment
•GreenAdjustment
•RedAdjustment
To use these tags, bind them to Numeric Input elements you put on your custom
screen. The default value for each color is 50. To make the color more or less
pronounced, enter higher or lower values using your Numeric Inputs.
Configure the Display
Screen Saver
The screen saver extends the life of the back light by dimming the brightness level
when activity is not sensed for a specified amount of time. When the screen saver
is activated, the terminal displays a moving image at a reduced brightness level.
When user input is sensed, the screen saver is deactivated and the display
brightness returns to its configured level.
To configure the brightness and screen saver for the display, follow these steps.
1. On an application screen, press .
2. On the Settings screen, tap .
TIP After the screen saver is deactivated, touch or keypad input is ignored for at
least 0.5 seconds.
