84 Rockwell Automation Publication 2713P-UM001G-EN-P - May 2022
Chapter 4
c. Select either USB Device or SD Card.
d. Click Export.
The alarm history is saved as a .zip file containing a .csv file. The .csv file
can be opened in Excel for further analysis.
View Automatic
Diagnostics
If you prefer, you can view automatic diagnostics for your controllers. This
capability is available for ControlLogix 5580 and CompactLogix 5380/5480
controllers (version 33 and later), and it automatically displays control system
faults with no HMI configuration required on your part.
To view automatic diagnostics, press the automatic diagnostics icon in the system
banner.
A diagnostics summary displays current diagnostic notifications.
You can switch the terminal language at runtime, and view the diagnostic
messages in the following languages:
•Portuguese
•French
