42 Rockwell Automation Publication 2713P-UM001G-EN-P - May 2022
Chapter 3
Figure 9 - Virtual Numeric Keypad
Specify Keypad or Keyboard
Size
If you prefer to work with a larger-size keypad or keyboard, PanelView provides a
larger size option.
To specify the keypad or keyboard size, follow these steps.
1. In View Designer, select Project Properties.
2. In the Project Properties dialog box, select Application in the left panel.
Table 16 - Virtual Numeric Keypad Description
Item Feature Description
1 Numeric entry field The numeric entry field into which you type the numeric value for the graphic
element.
2 Min-Max value The displayed minimum and maximum values you can enter for the selected field
or element.
3 Clear Tap the X to remove all numbers that are entered into the numeric entry field.
4 Backspace Tap the backspace button to delete one number to the left at a time.
5+
–
Tap the positive-negative value button to toggle between a positive or negative
number.
6 Cancel Tap Cancel to cancel the entry.
7 OK Tap OK to complete the entry.
