36 Rockwell Automation Publication 2713P-UM001G-EN-P - May 2022
Chapter 2
Linear Network Topology
A linear network topology is a collection of devices that are daisy-chained
together across an EtherNet/IP network. Devices that can connect to a linear
network topology use embedded switch technology so you do not need a
separate switch, as required in star network topologies.
Figure 6 - PanelView 5310 Terminal at the End of a Linear Network
Star Network Topology
A star network topology is a traditional EtherNet/IP network that has multiple
devices that are connected to each other via an Ethernet switch.
Figure 7 - PanelView 5310 Terminal Connected Via a Stratix 6000 Switch
P
a
n
e
l
V
i
e
w
5
3
1
0
T
e
r
mi
n
a
l
Kinetix 350 Drive Connected
Via a 1783-ETAP EtherNet/IP Tap
Kinetix® 350 Drive Connected
Via a 1783-ETAP EtherNet/IP Tap
1769-L27ERM-QBFC1B
Control System
1794-AENTR FLEX™ I/O Adapter
with FLEX I/O Modules
1734-AENTR POINT I/O™ Adapter
with POINT I/O Modules
Computer
P
a
n
e
l
V
i
e
w
5
5
1
0
T
e
r
mi
n
a
l
Computer
Stratix® 6000
Switch
1734-AENTR POINT I/O Adapter
with POINT I/O Modules
Kinetix 350
Drive
1769-L27ERM-QBFC1B
Control System
PanelView 5310
Ter mi na l
Kinetix 350
Drive
To Next Page
