Serial Communications
8-17
The information in the data table listed below was obtained from a
150 Hp motor, 1800 RPM rated at 480 volts. The motor has been
operating continuously for a period of 72 hours.
Refer to Appendix B and apply the scale factor to above parameters in the data table below.
Parameter
Description
Parameter
Number
Display
Value
Parameter
Description
Parameter
Number
Display
Value
Voltage Phase A–B 1 470 Wattmeter
7
90.0
Voltage Phase A–B 2 474 Kilowatt Hours 8 82
Voltage Phase A–B 3 469 Elapsed Time 9 72
Current Phase A
4
120.0 Power Factor
10
.92
Current Phase B
5
120.0
Motor Thermal
Usage
11 80
Current Phase C
6
120.0
Address Data (Radix = BINARY)
B3:0 0000 0000 0000
Address Data (Radix = BINARY)
N10:0 128 64 0 0 0 0 0 0 0 0
N10:10 4 1 11 1 0 0 0 0 0 0
N10:20 0 0 0 0 0 0 0 0 0 0
N10:30 0 0 0 0 0 0 0 0 0 0
N10:40 0 0 0 0 0 0 0 0 0 0
N10:50 0 0 0 0 0 0 0 0 0 0
N10:60 0 0 0 0 0 0 0 0 0 0
N10:70 0 0 0 0 0 0 0 0 0 0
N10:80 0 0 0 0 0 0 0 0 0 0
N10:90 0 0 0 0 0 0 0 0 0 0
N10:100 0 64 0 0 0 0 0 0 0 0
N10:110 15 1 11 1 470 474 469 1200 1200 1200
N10:120 900 82 72 92 80 0 0 0 0 0
N10:130 0 0 0 0 0 0 0 0 0 0
N10:140 0 0 0 0 0 0 0 0 0 0
N10:150 0 0 0 0 0 0 0 0 0 0
N10:160 0 0 0 0 0 0 0 0 0 0
N10:170 0 0 0 0 0 0 0 0 0 0
N10:180 0 0 0 0 0 0 0 0 0 0
N10:190 0 0 0 0 0 0 0 0 0 0
N10:200 0
M0:1 File Length: 3300
M0:2 File Length: 0
M0:3 File Length: 0
M0:4 File Length: 0
M1:1 File Length: 3300
M1:2 File Length: 0
M1:3 File Length: 0
M1:4 File Length: 0
Address Data (Radix = BINARY)
G1:0 2020 0001 000F
