Rockwell Automation SMC Dialog Plus User Manual

Troubleshooting
10-7
180–360 Amp
Refer to Figure 10.3 for control module reference.
1. Remove controller access door and serial port cable.
2. Remove controller cover.
3. Remove all control wires and loosen six control module mounting
screws.
4. Unplug control module from the interface board by pulling for-
ward.

Rockwell Automation SMC Dialog Plus Specifications

General

Brand	Rockwell Automation
Model	SMC Dialog Plus
Category	Controller
Language	English
