Rockwell Automation SMC Dialog Plus User Manual

Parameter Information
B-5
Table B.2 Parameter Text/Display Unit Cross Reference
①
Pump Start is only available with the Pump Control option.
②
Dual Ramp is only available with the standard controller.
③
Slow Speed Select is only available with the Preset Slow Speed and Accu-Stop options.
④
Slow Speed Direction is only available with the Preset Slow Speed option.
Parameter Number Description Setting Text Display Unit
14 SMC Option
Standard 0
Soft Stop 1
Pump Control 2
Preset Slow Speed 3
Smart Motor Braking 4
Accu-Stop 5
Slow Speed with Braking 6
15 ETM Reset
Off 0
On 1
17 Parameter Mgmt.
Ready 0
Default Init 1
Recall From EE 2
Store In EE 3
18 Clear Fault
No 0
Yes 1
28 Starting Mode
Current Limit 0
Soft Start 1
Pump Start
①
2
29 Dual Ramp
②
No 0
Yes 1
36 Overload Class
Off 0
10 1
15 2
20 3
30 4
38 Energy Saver
Off 0
On 1
39 Aux Contacts 1&2
Normal 0
Up-to-speed 1
40 Aux Contact 3
Normal 0
Fault 1
41 Contact 3 Config
N.O 0
N.C. 1
44
Slow Speed Select
③
Low 0
High 1
45
Slow Speed
Direction
④
Reverse 0
Forward 1
59 Rebalance
Off 0
On 1
62 Phase Reversal
Off 0
On 1
