Rockwell Automation SMC Dialog Plus User Manual

Renewal Parts
C-3
①
One piece provided per part number.
②
Protective modules are available as a fieldñinstalled accessory. See Appendix D.
Description SMC Rating Line Voltage
Part Number
①
Individual SCRs
24–500A 200–480V N/A
650A 200–480V 40382-811-01
720A 200–480V 40382-811-03
850A 200–480V 40382-812-03
1000A 200–480V 40382-812-01
24–500A 200–600V N/A
650A 200–600V 40382-811-02
720A 200–600V 40382-811-04
850A 200–600V 40382-812-04
1000A 200–600V 40382-812-02
Interface Board
24–135A All N/A
180–360A All 40382-805-01
500A All 40382-814-01
650–1000A All 40382-814-02
Heatsink Fans
24–54A All N/A
97–135A All 40382-807-01
180–360A All 40382-804-01
500A All 40382-813-01
650–1000A All 40382-815-01
MOV Fuse
24–360A All N/A
500–1000A All 40382-816-01
MOV
24–360A 200–480V
②
500–1000A 200–480V 40382-817-01
24–360A 200–600V
②
500–1000A 200–600V 40382-817-02
