7-4
Options
Programming Parameters (cont.)
①
All braking/stopping current settings in the range of 1–100% will provide 100% braking current to
the motor.
SMB Smart
Motor Braking
SMC Option
This parameter identifies the type of
control present and is not user
programmable.
SMB Braking
Braking Current
①
Allows the user to program the intensity
of the braking current applied to the
motor.
0–400% of full load
current
Accu-Stop
SMC Option
This parameter identifies the type of
control present and is not user
programmable.
Accu-Stop
Slow Speed Select
Allows the user to program the slow
speed that best fits the application.
Low: 7%
High: 15%
Slow Accel Current
Allows the user to program the required
current to accelerate the motor to slow
speed operation.
0–450% of full load
current
Slow Running Current
Allows the user to program the required
current to operate the motor at the slow
speed setting.
0–450% of full load
current
Braking Current
①
Allows the user to program the intensity
of the braking current applied to the
motor.
0–400% of full load
current
Stopping Current
①
Allows the user to program the
intensity of the braking current
applied to the motor from slow
speed operation.
0–400% of full load
current
Slow Speed
with Braking
SMC Option
This parameter identifies the type of
control present and is not user
programmable.
Slow Speed Brake
Slow Speed Select
Allows the user to program the slow
speed that best fits the application.
Low: 7%
High: 15%
Slow Accel Current
Allows the user to program the
required current to accelerate the
motor to slow speed operation.
0–450% of full load
current
Slow Running Current
Allows the user to program the
required current to operate the
motor at the slow speed setting.
0–450% of full load
current
Braking Current
①
Allows the user to program the
intensity of the braking current
applied to the motor.
0–400% of full load
current
