Options
7-15
Figure 7.11 Typical Retrofit Wiring Diagram
①
Customer supplied.
②
Overload protection should be disabled in the SMC Dialog Plus controller.
③
Refer to the controller nameplate to verify the rating of the control power input voltage.
④
Slow Speed or Accu-Stop.
Note: Refer to Chapter 3 for typical power circuits.
Stop
➀
OL
➀ ➁
M
➀
Control Power
➂
Option Command
➀ ➃
Start
➀
11 12 13 14 15 16 17 18 19 20
21 22 23 24 25 26 27 28 29 30
Internal
Auxiliary
Contacts
Auxiliary contacts set
for Normal
SMC Dialog Plus
Control Terminals
To Next Page
