2.2.8) Removal of piston
General See Figure 5.
Special tools The following special tools and equipment are required:
Instructions Proceed as follows to remove the piston:
In order to protect the piston pin circlip from uninten-
tional loss in the crankcase, a suitable clean cloth
should be used to cover the open cylinder bore.
Always support the piston with the hand in order to
avoid a bending moment.
Part number Description Use
Part no. 676035 Insertion tool Piston
Part no. 976380 Circlip puller Circlip
Step Procedure
1 Pull out the circlip (1) with the circlip puller (3). Use safety glasses!
2 Press the piston rod out of the piston and con rod with the point of the special
tool (3).
