DK00029.fm
REPAIR MANUAL
BRP-Powertrain
Effectivity: 125 MAX/125 Junior MAX/125 Mini
MAX/125 Micro MAX
Edition 2 / Rev. 0
Chapter 7
Page 3
December 01/2010
1) System description
Overview Position on the engine
Figure 1
K00140
Part Function
1 Starter gear assembly
2 Clutch drum
3 Sprocket
3
1
2
